17 - 82 Operator’s Manual
17 Probes and Biopsy
• http://www.civco.com
Perform the following procedure:
1. Refer to “6.15.2 Magnetic Navigator” for installation of magnetic controller, auxiliary power
line, USB cable, magnetic generator and probe sensor. Abdomen sensor is necessary under
Fusion imaging mode.
2. Connect the needle sensor to the 3rd port on the magnetic controller.
3. Put on the sterile sheath onto the needle sensor.
4. Insert the sensor into the needle.
5. Tighten the knob, and make sure not to break the sterile sheath.
6. Turn on the magnetic navigator power and perform needle navigation guiding operation after
the signal is stabilized. Refer to “6.15.3 Screen Description” for details.
