When calibration/adjustment is complete, the GMP-compliant printout shown on
the left is generated. If the adjustment procedure is canceled (only calibration is
performed), the last two lines, “External calibration” and “Di. + 0.000 kg” are not
printed.
t Unload the scale.
t Press e to turn o the device.
t Press e turn the device back on.
y The Minebea Intec logo is displayed briey, after which the device is in normal
weighing mode.
3
If a serious operator error should occur during calibration (for example, if the menu
setting “Cal. then auto adj.“ is active and the wrong calibration
weight is placed on the scale), the scale might completely fail to stabilize, which
means it cannot show a zero point.
In this case, select the “
Adjust without weights“ menu and set the
mean sensitivity of the strain-gauge weighing beam to 2.0 mV/V.
Then re-adjust the scale.
See also “Adjust without weights.“
The zero point is only displayed for a veried scale with d=e.
External Calibration/Adjustment
with a User-Dened Weight
Conguration Select the “CAL key function:Ext. cal./adj.; user-
def. wt.
“ menu item (external adjustment using a user-dened weight).
Note:
The menu items “Ext. cal./adj.; factory-def. wt.“
(external adjustment with a factory-dened, standard weight), “Ext. cal./
adj.; user-defined wt.
“ (external adjustment with a user-dened
weight) and “Key blocked“ can also be accessed without activating the
Service mode.
t Use the “Q“ or “q“ soft key to select this menu item and conrm with “l.“
y The menu item is marked as set by a circle “o.“
t Enter the target value of the adjustment weight in the “Calibration/
adjustment
“ menu under “Parameter for external
weight
“ in the “Cal/adj. wt“ input eld.
--------------------
24.02.2016 10:15
Typ CAW3S
Ser.no. 12345678
Vers. H0 111.031115
BVers. 01-63-02
Ser.no. A 12345678
--------------------
Ext. Calibration
Nom + 5000 g
Diff. + 10 g
Ext. adjustment
Diff. + 0 g
--------------------
24.02.2016 10:17
Name:
--------------------
Operating Instructions Combics Complete Scales 41
Configuring Weighing Platforms
