⑤ Reading out the unit (Host → CSD-904-EX)
2 4 6
@ 0 0 4 2 Terminator
Return (CSD-904-EX → Host)
2 4 6 8 10 12 14
@ 0 0 4 2 a b c Terminator
Unit a b c
No Unit 0 0 0
g 0 0 1
kg 0 1 0
t 0 1 1
lb 1 0 0
⑥ Change of condition (Host → CSD-904-EX)
2 4 6
@ 0 0 5 0 Terminator
At normal operation
Return (CSD-904-EX → Host)
2 4 6
@ 0 0 5 0 Terminator
At abnormal operation
Return (CSD-904-EX → Host)
2 4 6 8
@ 0 0 E R 0 2 Terminator
The condition of the error transmission becomes as follows.
● When the zero set cannot be executed outside the effective range of zero setting in executing the zero set of “Command No. 50”.
● When the tare weight cancellation cannot executed with the display of “±OL” in executing the tare weight cancellation of “Command No.51”.
● When the accumulation cannot be executed by the accumulated value overflow in executing the accumulation of “Command No. 53”.
● When the switch to the net value display cannot be made by unexecution of tare weight cancellation in executing the net value display of
“Command No.59”.
Address
00～31
Command No.
Command No.
42
Operation
Reading out the unit
Address
00～31
Command No.
Condition
Space
Address
00～31
Command No.
Command No.
50
59
51
52
53
54
58
Operation
Zero set
Tare weight cancellation
Tare weight cancellation clear
Accumulation
Accumulation value clear
Display of gross value
Display of net value
Address
00～31
Command No.
Address
00～31
