4. Getting started
MiR200 User Guide (en) 10/2020 - v.3.1 ©Copyright 2017-2020: Mobile Industrial Robots A/S. 44
NOTICE
The nameplate must be mounted as described in the following steps. If
mounted incorrectly, the CEmark is invalid.
The following steps describe how to mount the nameplate correctly:
1. Locate the area below the side cover near the swivel wheel at the rear end of the robot—
see External parts on page11.
2. Clean the area marked in the image below with a degreasing agent. If you cannot access
the area, either lift the robot to an appropriate height or remove the top cover to gain
access.
3. Mount the nameplate on the cleaned area.
