Page #74 background image
74
Appendix B: RA-1000 Remote Annunciator Panels
12.0 Appendix B: RA-1000 Remote
Annunciator Panels
12.1 RA-1000 Series
The RA-1000 Series of remote annunciators are units with electrical modules and enclosures
matching the configurations of the FA-1000 Series Fire Alarm Control Panels. For detailed
information see Mircom Documents RA-1000 Manual LT-617, RAM-208 Manual LT-648, RAM-
216 Manual LT-658 and MGD-32 Manual LT-847.
12.1.1 Models
RAM-1032(TZ) Main Annunciator Chassis with common indicators and controls, and
32-circuit capacity (TZ Version has 32 Trouble LEDs)
RAX-1048(TZ) Adder Annunciator Chassis with 48 circuit capacity
RAM-1016(TZ) Non-Expandable Annunciator Chassis with common indicators and
controls, and 16-circuit capacity (TZ Version has 16 Trouble LEDs)
RAM-208 Non-Expandable Annunciator Chassis with limited common indicators and
controls, and eight-circuit capacity
RAM-216 Non-Expandable Annunciator Chassis with limited common indicators and
controls, and 16-circuit capacity
MGD-32 Main Graphic Annunciator Chassis with common indicators and controls, and
32-circuit capacity
AGD-048 Adder Graphic Annunciator Chassis with 48-circuit capacity
12.1.2 Enclosures
BB-1001 with capacity for one annunciator chassis
BB-1002 with capacity for two annunciator chassis
BB-1003 with capacity for three annunciator chassis
BB-1008 with capacity for eight annunciator chassis
BB-1012 with capacity for twelve annunciator chassis
Finish: Painted, textured, off-white (standard) (for other paint available colors
and finishes, please contact factory)
Material:18 G.A. cold roll steel (CRS)
i
