78
Appendix C: Specifications
13.3 FA-1000 Expander Chassis and System Modules
Compliance System Model FA-1000 Series Fire Alarm Control Panel
System Type Local, auxiliary (using PR-300), remote protected
premises station (using PR-300 or UDACT-300A),
central station protected premises (using UDACT-
300A).
Type of Service A, M, WF, SS
Type of Signalling Non-Coded
Applicable Standards NFPA 70 and 72, UL 864 R9, ULC S-524, ULC S-
527-11, CAN/ULC-S559-04 1st edition
Table 17 FA-1000 Expander Chassis and System Modules
FA-1000 System Modules and Annunciators
ECH -1048 Expander Chassis Up to six circuit adder modules may be added.
Displays and disconnect switches for up to 48
circuits.
Current Consumption standby: 80 mA / alarm: 100 mA
SGM-1004A Signal Adder Module Four Class B or A (Style Y or Z) NAC circuits;
configurable as strobes or audibles. Terminals
are labelled "IND".
Power Limited: 24 VDC unfiltered max. 1.7 amps @ 49C per
circuit
Current Consumption standby: 35 mA / alarm: 150 mA
RM-1008A
(resistive loads)
Relay Adder Module Must be connected to a listed power limited
source of supply. Terminals are labelled "RLY".
Eight fully configurable Form C NAC.
Form C, 1 amp., 28 VDC (resistive loads)
Current Consumption standby: 25 mA / alarm: 150 mA
Table 16 MCC-1024-12[SA] and MCC-1024-12ADS Specifications (Continued)
MCC-1024-12[SA] and MCC-1024-12ADS Chassis
