13.1 MCC-1024-6[SA] and MCC-1024-6ADS Specifications
Table 15 MCC-1024-6[SA] and MCC-1024-6ADS Specifications
MCC-1024-6[SA] and MCC-1024-6ADS Chassis
General Micro-controller based design, fully configurable from front panel, full walk test
function. Up to two circuit adder modules may be added. Displays and
disconnect switches for up to 24 circuits. Optional PR-300 City Tie Module.
Initiating Circuits Eight supervised Style B (Class B) or 4 Style D (Class A) initiating circuits; fully
configurable. Terminals are labelled INI. initiating circuits are Compatibility ID
"A".
Power Limited: 22 VDC, 3 mA standby, 5 mV ripple, 50 mA max. (alarm)
Indicating Circuits Four Style Y or Z (Class B or A) indicating circuits; configurable as strobes or
audibles. Terminals are labelled IND.
Power Limited: 24 VDC unfiltered, 1.7 amps @ 49 C per circuit 5 A maximum
Aux. Power Supply. Terminals are labelled AUX PWR.
Power limited / 24 VDC Filtered (special application) / 1.7 A @ 49° C
Two Resettable 4-Wire
Smoke Supplies
Terminals are labelled 4-WIRE.
Power Limited: 22 VDC, 200 mA each max., 300 mA total max, 5 mV ripple
RS-485 Connection 1 RS-485 Connection for Remote Annunciators or interface to Audio Systems.
Terminals are labelled RS485.
Power Limited to 300 mA.
Electrical ratings AC Line Voltage 120V 60Hz / 240V 50 Hz
2A / 1A primary
Power supply ratings 6 Amps. max. (secondary)
For indicating circuits 24VDC unfiltered, 5 Amps. max.
Auxiliary relays
(resistive loads)
Must be connected to a listed power limited source of supply. Terminals are
labelled "ALARM, TROUBLE, SUPV".
Common alarm Form C, 1 Amp, 28 VDC
Common Supv Form C, 1 Amp, 28 VDC
Common Trouble Form C, 1 Amp, 28 VDC
Type 24VDC, Gel-Cell/Sealed Lead-Acid
Battery Charging capability 10Ah to 24Ah batteries
Current Consumption standby: 200 mA
alarm: 350 mA
