Appendix C: Specifications
PR-300 Polarity Reversal and City Tie Module Supervised city tie--not power limited
24VDC unfiltered, 210 mA max., Trip coil: 14
ohms.
Terminals are labelled "City Tie".
Polarity reversal power limited
Terminals are labelled "Polarity Reversal".
24VDC open
12VDC @ 3.5 mA, 8 mA max. (shorted)
Current Consumption standby: 35 mA / alarm: 300 mA
DM-1008A Detection Adder Module Eight supervised Class B (Style B) or four
Class A (Style D) NAC circuits; fully
configurable. Terminals are labelled "INI". NAC
circuits are Compatibility ID "A".
Power Limited 22VDC, 3 mA standby, 5mV ripple, 50 mA
max. (alarm)
Current Consumption standby: 80mA
alarm: 100 mA
UDACT-300A Digital Communicator Module Transmit alarm, supervisory, and trouble to a
central monitoring station using Ademco
Contact ID and SIA-DCS Protocols.
Current Consumption standby: 45 mA / alarm: 120 mA
Table 17 FA-1000 Expander Chassis and System Modules (Continued)
FA-1000 System Modules and Annunciators
