82 TX3 Telephone Access System Installation and Operation Manual Version 5.4

NSL Relay Cabinet Installation and Wiring

2. Using a jumper, set the backplane number across the Backplane Number

Selection pins as shown in figure 48.

Figure 48. Backplane Number Section

Jumper Setting

Backplane Number

Selection
