SECTION MITL9105/91
lo-096-350~NA
TABLE 4-4 (CONT’D)
ERROR CODES
Code Major/
Minor
E023 major
Slot
20
Reason
Battery
Backup
problem
First three digits
of Destination
Display
001 = battery
switch open
002 = voltage
out-of-
tolerance
Last three digits See
of Destination
Note
Display
E030 minor
. . . Slot Trunk Failure 001 = no
number seize acknowledge
002 = no release
acknowledge
E088 minor Automatic
Wake-up not
answered
Extension
E096 minor
E098 minor
Slot SUPERSET Set SUPERSET Set
number disconnected number
--
Printer Port
disabled
E099 minor
--
Extension
locked out
Extension
number
Notes: 1. No more tests using the check circuit will be performed.
_-.
: .-
2.
The speech path shown in the first two digits of DESTINATION display is busied-out;
a maximum of 16 speech paths may be busied-out.
3.
The receiver is busied-out; maximum one receiver on a Dual-Receiver card and two
receivers on a Quad-Receiver card.
4. The generator is busied-out; maximum one. No further generator tests are
performed.
5. No further tests on this slot are performed at this time. This error will occur if a
card is not installed for the programmed line or trunk
6. No further test for supervisory tone presence are performed.
7. No further tests are performed.
8. E021 will reappear if the system is reset. If E021 is not cleared by initializing the
MM and reprogramming the system, replace the IPC card.
