the call is not allowed, reorder tone will be returned from the Tone
Control card and the trunk will be released.
Tables
5.24 Table 5-1 is a list of all tables to be used in the actual trouble-
shooting of the SX-lOO/SX-200 system. Table 5-2 is a list of
the error codes that may appear on the console during regular opera-
tion, Table 5-3 is a list of extension faults, Table 5-4 is a list of
console faults, Table 5-5 is a list of trunk. faults and Table 5-6 is a list
of system faults. All tables suggest immediate remedial action or
provide a direct reference to a .MAP that will incorporate the proper
actions.
TABLE 5-1
TABLE LISTING FOR TROUBLESHOOTING
-.
. _..
.-L
:
. .
Table
Title
5-2
Error Code Procedures
5-3
Extension Fault Report Procedures
5-4 Console Faults
5-5
Trunk Fault Report Procedures
5-6
System Faults
5.25 In the following tables (5-2 to 5-6) a STOP indication should be
taken as: STOP; contact your nearest authorized MITEL Service
representative.
