SECTION MITL91 OS/91 1 O-096-350-NA
;. .
EXPOSE THE SYSTEM (SX-100)
MAP350- 400
Issue 3, May 1984
Sheet 2 of 7
CABINET DOOR
EQUIPMENT SHELF
FRONT VIEW
MAINTENANCE PANEL
PRIMARY POWER SWITCH
. POWER SUPPLY
WEIGHT HEIGHT
1 WIDTH 1 DEPTH
31.8 kg 422 mm 635 mm 470 mm
VO lb)
(16.62 in.] (25 in.) (18.5 in.)
PRIMARY POWER SUPPLV CABLE CLAMPS
4 c
. -
REAR VIEW
x561
Figure 400-l SX-100 Cabinet-Mount
Page D-4
