4G1 ENGINE (E-W) -
Crankshaft and Cylinder Block
11A-12-2a
PWEE9520
E
Nov. 1995Mitsubishi Motors Corporation
REMOVAL AND INSTALLATION <GDI>
Apply engine oil to all
moving parts before
installation.
19 Nm
13
10 Nm
18
14
34 Nm + 30
_
to 34
_
10 Nm
16
2
3
4
6
7
8
10
12
19
98 Nm
15
17
23 Nm
10
11
11 Nm
5
9
1
Removal steps
"
F
A
1. Drive plate bolt
2. Adapter plate
3. Drive plate
4. Crankshaft bushing
5. Rear plate
6. Bell housing cover
"
E
A
7. Rear oil seal case
"
D
A
8. Rear oil seal
9. Bearing cap bolt
"
C
A
10. Bearing cap
"
C
A
11. Bearing cap No. 4
"
C
A
12. Bearing cap center
"
B
A
13. Crankshaft bearing, lower
14. Crankshaft
"
B
A
15. Crankshaft bearing, upper
"
B
A
16. Crankshaft bearing, center
A
A
""
A
A
17. Oil pressure switch
18. Knock sensor
19. Cylinder block
PWEE9520-D
E
Aug. 2000Mitsubishi Motors Corporation Added
