Mitsubishi 4G1 series General Information

4G1 ENGINE (E-W) -
Specifications
11A-1-5
PWEE9520
E
Nov. 1995Mitsubishi Motors Corporation
Item Nm
Intake manifold and throttle body (GDI)
Accelerator cable bolt 10
Throttle body bolt 19
Air intake plenum resonator bolt 10
Power plant stay right bolt 49
Intake manifold stay bolt 30
EGR valve bolt 19
EGR valve support bolt 19
EGR valve support nut 24
Intake manifold bolt, nut 20
Exhaust manifold (GDI)
Oxygen sensor 44
Exhaust manifold cover bolt 30
Exhaust manifold bracket bolt 35
Exhaust manifold nut (M8) 18
Exhaust manifold nut (M10) 29
Power plant stay left bolt 35
Water pump and water hose
Water inlet fitting bolt 22
Water inlet pipe bolt (M8) 12
Water inlet pipe bolt (M10) 25
Fitting bolt 23
Water outlet fitting bolt (Front wheel drive) 23
Water outlet fitting bolt (Rear wheel drive) 18
Thermostat case bolt 23
Thermo valve 27
Engine coolant temperature gauge unit 11
Engine coolant temperature sensor 29
Water pump bolt 13
Exhaust manifold and intake manifold
Boost sensor bolt 5
Solenoid valve assembly bolt 9
Intake manifold bolt, nut 17
Intake manifold stay bolt <MPI> (M8) 17
Intake manifold stay bolt <MPI> (M10) 31
Intake manifold stay bolt <carburetor> 30
Engine hanger bolt 19
Exhaust manifold cover bolt 29
PWEE9520-D
E
Aug. 2000Mitsubishi Motors Corporation Revised
