Mitsubishi 4G1 series General Information

4G1 ENGINE (E-W) -
Specifications
4G1 ENGINE (E-W) -
Specifications
4G1 ENGINE (E-W) -
Specifications
11A-1-5a
PWEE9520
E
Nov. 1995Mitsubishi Motors Corporation
Item Nm
Exhaust manifold nut (M8) 17
Exhaust manifold nut (M10) 29
Exhaust manifold bracket A bolt 35
Exhaust manifold bracket B bolt 35
Power plant stay right bolt 49
Power plant stay left bolt 35
Oxygen sensor 44
Fuel system (GDI)
Fuel pipe bolt 12
Fuel pump bolt 4.9
®
17
±
2
Flange bolt 24
Harness bracket bolt 9.8
Injector holder bolt 23
Delivery pipe and injector bolt 12
Rocker arms and camshaft
Fuel pump cover bolt 12
Rocker cover bolt <SOHC> 3.5
Rocker cover bolt <DOHC> 4
Rocker shaft assembly bolt 31
Adjusting screw 15
Bearing cap bolt (M6) 11
Bearing cap bolt (M8) 24
Rocker arms and camshaft (GDI)
Engine hanger bolt 19
Rocker cover bolt 3.5
Beam camshaft cap bolt (M6) 11
Beam camshaft cap bolt (M8) 25
Cylinder head and valves
Cylinder head bolt 20 + 90
_
+90
_
Tighten to 49 Nm, then completely loosen and retighten as described.
Oil pump and oil pan
Transmission stay bolt 23
Oil pan bolt (M6) 7
Oil pan bolt (M8) 24
Drain plug 39
Oil screen bolt 19
Front case bolt 14
Relief plug 44
PWEE9520-D
E
Aug. 2000Mitsubishi Motors Corporation Revised
