4G1 ENGINE (E-W) -
Water Pump and Water Hose
11A-6-2b
PWEE9520
E
Nov. 1995Mitsubishi Motors Corporation
REMOVAL AND INSTALLATION <SOHC 16-VALVE- MPI - REAR WHEEL DRIVE>
2
13 Nm
12
11
10
12 Nm
11 Nm
4
1
25 Nm
9
8
23 Nm
18 Nm
5
7
6
29 Nm
3
12 Nm
Removal steps
1. Water hose
2. Water hose
"
E
A
3. Engine coolant temperature sensor
"
D
A
4. Engine coolant temperature gauge
unit
5. Water outlet fitting
6. Gasket
"
C
A
7. Thermostat
8. Fitting
9. Gasket
"
B
A
10. Water inlet pipe
"
B
A
11. O-ring
"
A
A
12. Water pump
PWEE9520-D
E
Aug. 2000Mitsubishi Motors Corporation Revised
To Next Page
