Mitsubishi 4G1 series General Information

4G1 ENGINE (E–W) – Water Pump and Water Hose
11A-6-2c
PWEE9520
E
Nov. 1995Mitsubishi Motors Corporation
REMOVAL AND INSTALLATION <SOHC 16-VALVE–MPI – FRONT WHEEL DRIVE
(FROM 2004 model FOR EUROPE)>
2
13 Nm
12
10
9
11
12 Nm
11 Nm
4
23 Nm
3
8
7
6
22 Nm
5
29 Nm
1
12 Nm
Removal steps
1. Water hose
2. Water hose
"EA 3. Engine coolant temperature sensor
"DA 4. Engine coolant temperature gauge
unit
5. Water inlet fitting
"CA 6. Thermostat
7. Thermostat case
8. Gasket
"BA 9. Water inlet pipe
"BA 10. O-ring
"BA 11. O-ring
"AA 12. Water pump
PWEE9520-G
E
Apr. 2003Mitsubishi Motors Corporation Added
