4G1 ENGINE (E-W) -
Intake and Exhaust Manifolds
11A-7-2e
PWEE9520
E
Nov. 1995Mitsubishi Motors Corporation
REMOVAL AND INSTALLATION <SOHC 16-VALVE- MPI - FRONT WHEEL DRIVE
(EXCEPT FROM 2001 model FOR EUROPE)>
17 Nm
1
3
4
5
6
7
2
31 Nm
5Nm
17 Nm
9Nm
49 Nm
17 Nm
11
10
17 Nm
9
29 Nm
19 Nm
8
35 Nm
29 Nm
12
Removal steps
1. Boost sensor
2. Engine hanger
3. Power plant stay right <CVT>
4. Intake manifold stay
5. Solenoid valve assembly
6. Intake manifold
7. Intake manifold gasket
8. Engine hanger
9. Exhaust manifold cover
10. Exhaust manifold
11. Exhaust manifold gasket
12. Power plant stay left <CVT>
PWEE9520-D
E
Aug. 2000Mitsubishi Motors Corporation Added
