FX Series Programmable Controlers Applied Instructions 5
5-203
5.16.1.1.7 EXTR K12 - Parameter read (Inverter to PLC)
Link parameters are automatically re-written in accordance with the parameter No.
5.16.1.1.8 EXTR K13 - Parameter write (PLC to Inverter)
Link parameters are automatically re-written in accordance with the parameter No.
16 Bit Operation
ü
32 Bit Operation
û
Pulse - P
û
Parameter Device type Parameter range
S1 K/H K12: function No. to read inverter parameters
S2 KH, D Inverter station number (0 to 31)
S3 KH, D Inverter instructuion code (varies with model)
S4 D, KnY, KnM, KnS Value of storage destination
16 Bit Operation
ü
32 Bit Operation
û
Pulse - P
û
Parameter Device type Parameter range
S1 K/H K13: function No. to write inverter parameters
S2 KH, D Inverter station number (0 to 31)
S3 KH, D Inverter instructuion code (varies with model)
S4 KH,D,KnX,KnY,KnM,KnS Valuetobewrittentoinverter
EXTR K12 K2 K3 D100
S1 S2 S3 S4
EXTR K13 K2 K3 K5600
S1 S2 S3 S4
