4.13 Index Registers
Device Mnemonic: V,Z
Purpose: To modify a specified device by stating an offset.
Alias: (V/ Z) Register
Index (register/ addressing/ modifier)
Offset(s) (register/ addressing/ modifier)
Indices
Modifier
Available forms:
For 16bit data V or Z
(2 devices)
For 32bit data V and Z combined
(1 device - Z is specified)
Operation is similar to data registers.
Devices numbers: 16 devices V0 - V7 and Z0 - Z7
Further uses: Can be used to modify the following devices under certain conditions;
X, Y, M, S, P, T, C, D, K, H, KnX, KnY, KnM, KnS
Example device usage:
The program shown right transfers data from D5V to D10Z.
If the data contained in register V is equal to 8 and the data in register Z is equal to 14, then:
V=8
D5V
D5 +8 =13 í D13
Z=14
D10Z
D10 + 14 = 24 í D24
Hence, the actual devices used after the modifiers V and Z have been taken into account are;
D13 and D24 and not D5 and D10 respectively.
Use of Modifiers with Applied Instruction Parameters:
• All applied instruction parameters should be regarded as being able to use index regis-
ters to modify the operand except where stated otherwise.
FX
1S
FX1N FX2N
FX2NC
V Z
V Z
32 Bit
16 Bit 16 Bit
