Mitsubishi FX1S Series User Manual

FX Series Programmable Controllers Devices in Detail 4
4-14
4.7 Constant K
Device Mnemonic: K
Purpose: Identification of constant decimal values
Alias: Constant
K (value/ constant)
K
Available forms: Numeric data value, when used for 16bit data, values can be selected from
the range -32,768 to +32,767
For 32bit data, values from the range -2,147,483,648 to + 2,147,483,647
can be used.
Devices numbered in: N/A. This device is a method of local instruction data entry.
There is no limit to the number of times it can be used.
Further uses: K values can be used with timers, counters and applied instructions
Example device usage: N/A
4.8 Constant H
Device Mnemonic: H
Purpose: Identification of constant hexadecimal values
Alias: Constant
H (value/ constant)
Hex (value/ constant)
H
Available forms: Alpha-numeric data value, i.e. 0 to 9 and A to F (base 16).
When used for 16bit data, values can be selected from the range 0 to
FFFF.
For 32bit data, values from the range 0 to FFFFFFFF can be used.
Devices numbered in: N/A. This device is a method of local instruction data entry.
There is no limit to the number of times it can be used.
Further uses: Hex values can be used with applied instructions
Example device usage: N/A
FX 1S
FX1N FX2N
FX2NC
FX 1S
FX1N FX2N
FX2NC

Mitsubishi FX1S Series Specifications

General

Model	FX1S Series
I/O Points	10 to 30 points
Program Memory	2000 steps
Power Supply	AC
Communication	RS-422
Expansion	No expansion
Programming Language	Ladder Logic
Input Voltage	100-240V AC
Built-in High-Speed Counter	Up to 60 kHz (single-phase)
Weight	Approx. 0.3 kg
Dimensions	90 x 60 x 75 mm
