Mitsubishi FX1S Series User Manual

FX Series Programmable Controller Diagnostic Devices 6
6-20
6.14 Miscellaneous devices (D8158 to D8164) and
Index Registers (D8182 to D8199)
For symbol key see page 6-1.
*1 See Chapter 10.19.2 for more information
Diagnostic
Device
Operation
Diagnostic
Device
Operation
D8158 (-)
(Not FX2N,FX2NC)
Control device for
FX
1N-5DM*1
Default: k-1
D8187 (
7)
Value of V3 index register
D8159 (-)
(Not FX2N,FX2NC)
Control device for
FX
1N-5DM*1
Default: k-1
D8188 (7)
Value of Z4 index register
D8164 (-)
(Not FX1S,FX1N)
Number of FROM/TO
exchange points
(FX2N/2NC CPU Version 2.00 and
above)
D8189 (7)
Value of V4 index register
D8181 (
7)
Reserved
D8190 (7)
Value of Z5 index register
D8182 (
7)
Value of Z1 index register
D8191 (7)
Value of V5 index register
D8183 (
7)
Value of V1 index register
D8192 (7)
Value of Z6 index register
D8184 (
7)
Value of Z2 index register
D8193 (7)
Value of V6 index register
D8185 (
7)
Value of V2 index register
D8194 (7)
Value of Z7 index register
D8186 (
7)
Value of Z3 index register
D8195 (7)
Value of V7 index register
FX 1S
FX 1N FX 2NC FX 2N

Mitsubishi FX1S Series Specifications

General

Model	FX1S Series
I/O Points	10 to 30 points
Program Memory	2000 steps
Power Supply	AC
Communication	RS-422
Expansion	No expansion
Programming Language	Ladder Logic
Input Voltage	100-240V AC
Built-in High-Speed Counter	Up to 60 kHz (single-phase)
Weight	Approx. 0.3 kg
Dimensions	90 x 60 x 75 mm
