Mitsubishi FX1S Series User Manual

FX Series Programmable Controlers Applied Instructions 5
5-125
5.9.7 VRSD (FNC 86)
Operation:
The identified volume (S) on the FX-8AV is read as
a rotary switch with 11 set positions (0 to 10). The
position data is stored at device D as an integer
from the range 0 to 10.
Mnemonic Function
Operands
Program steps
SD
VRSC
FNC 86
(Volume
scale)
Reads the set
position value, 0
to 10, from
volume inputs on
the FX-8AV
K, H
Note:
S= 0 to 7
corresponding to the 8 avail-
able
volumes on the FX-8AV
KnY, KnM, KnS
T, C, D, V, Z
VRSC,
VRSCP:
5steps
FX 1S
FX 1N FX 2N
FX 2NC
PULSE-P 16 BIT OPERATION 32 BIT OPERATION
[ S ] [ D ]
X0
VRSC K 1 D 1
Note:
The FX-8AV volume ‘inputs’ areabletobereadintwoformats,a)asa11(0to10)position
rotary switch and b) as an analog value. The second use is described in the
VRRD
instruction (FNC 85).

Mitsubishi FX1S Series Specifications

General

Model	FX1S Series
I/O Points	10 to 30 points
Program Memory	2000 steps
Power Supply	AC
Communication	RS-422
Expansion	No expansion
Programming Language	Ladder Logic
Input Voltage	100-240V AC
Built-in High-Speed Counter	Up to 60 kHz (single-phase)
Weight	Approx. 0.3 kg
Dimensions	90 x 60 x 75 mm
