5.1 Program Flow-Functions 00 to 09
Contents:
Page
CJ - Conditional jump FNC 00 5-5
CALL - Call Subroutine FNC 01 5-7
SRET - Subroutine Return FNC 02 5-8
IRET - Interrupt Return FNC 03 5-9
EI - Enable Interrupt FNC 04 5-9
DI - Disable Interrupt FNC 05 5-9
FEND - First End FNC 06 5-11
WDT - Watchdog Timer FNC 07 5-12
FOR - Start of a For/Next Loop FNC 08 5-13
NEXT - End a For/Next Loop FNC 09 5-13
FX
1S
FX
1N
FX
2N
FX
2NC
Symbols list:
D - Destination device.
S - Source device.
m, n- Number of active devices, bits or an operational constant.
Additional numeric suffixes will be attached if there are more than one operand with the same
function e.g. D
1,S3 or for lists/tabled devices D3+0, S+9 etc.
MSB - Most Significant Bit, sometimes used to indicate the mathematical sign of a number, i.e.
positive = 0, and negative = 1.
LSB - Least Significant Bit.
Instruction modifications:
PPP - An instruction operating in 16 bit mode, where PPP identifies the instruction
mnemonic.
PPPP - A 16 bit mode instruction modified to use pulse (single) operation.
DPPP - An instruction modified to operate in 32 bit operation.
DPPPP - A 32 bit mode instruction modified to use pulse (single) operation.
( - A repetitive instruction which will change the destination value on every scan unless
modified by the pulse function.
) - An operand which cannot be indexed, i.e. The addition of V or Z is either invalid or will
have no effect to the value of the operand.
