FX Series Programmable Controlers Applied Instructions 5
5-91
5.7.6 STMR (FNC 65)
Operation:
The designated timer Swill operate for the duration
n with the operational effect being flagged by
devices D+0to D+3. Device D+0is an off-delay
timer, D+1is a one shot timer. When D+3 is used in
the configuration below, D+1and D+2act in a
alternate flashing sequence.
Mnemonic Function
Operands
Program steps
SnD
STMR
FNC 65
(Special
timer)
Provides
dedicated
off-delay, one
shot and flash
timers
T
Note:
Timers0to199
(100msec
devices)
K, H
)
Note:
n=
1to32,767
Y, M, S
Note:uses 4
consecutive
devices
D+0to D+3
STMR:
7steps
FX 1S
FX 1N FX 2N
FX 2NC
PULSE-P 16 BIT OPERATION 32 BIT OPERATION
X0
K 100 M 0
[ S ]
[ D ]
T 10STMR
[ n ]
X0
M0
M1
M2
M3
X0
K 100 M 0T 10STMR
M3
X0
M2
M1(M3)

Mitsubishi FX1S Series Specifications

General

Model	FX1S Series
I/O Points	10 to 30 points
Program Memory	2000 steps
Power Supply	AC
Communication	RS-422
Expansion	No expansion
Programming Language	Ladder Logic
Input Voltage	100-240V AC
Built-in High-Speed Counter	Up to 60 kHz (single-phase)
Weight	Approx. 0.3 kg
Dimensions	90 x 60 x 75 mm
