Mitsubishi FX1S Series User Manual

FX Series Programmable Controllers Devices in Detail 4
4-7
4.4.2 Battery Backed/ Latched State Relays
There are a number of battery backed or latched relays whose status is retained in battery
backed or EEPROM memory. If a power failure should occur all output and general purpose
relays are switched off. When operation is resumed the previous status of these relays is
restored.
Available devices:
• For more information about device availability for individual PLC’s, see chapter 8.
External loads:
• State relays are provided with countless number of NO contact points and NC contact
points, and are freely available for use through out a PLC program. These contacts
cannot be used to directly drive external loads. All external loads should be driven
through the use of direct (ex. Y) outputs.
PLC FX1S FX1N FX2N FX2NC
General state
relays
N/A N/A
500
(S0 - 499)
Battery backed/
latched relays
128
(S0 - 127)
1000
(S0 - 999)
500
(S500 - 999)
Total available 128 1000 1000

Mitsubishi FX1S Series Specifications

General

Model	FX1S Series
I/O Points	10 to 30 points
Program Memory	2000 steps
Power Supply	AC
Communication	RS-422
Expansion	No expansion
Programming Language	Ladder Logic
Input Voltage	100-240V AC
Built-in High-Speed Counter	Up to 60 kHz (single-phase)
Weight	Approx. 0.3 kg
Dimensions	90 x 60 x 75 mm
