FX Series Programmable Controlers Applied Instructions 5
5-8
Special subroutine timers:
• Because of the chance of intermittent use of the subroutines, if timed functions are
required the timers used must be selected from the range T192 to T199 and T246 to
T249.
Details of using CALL with other program flow instructions
• Further details can be found on pages 7-12 and 7-13 about the combined use of different
program flow techniques (such as master control, MC etc).

Mitsubishi FX1S Series Specifications

General

Model	FX1S Series
I/O Points	10 to 30 points
Program Memory	2000 steps
Power Supply	AC
Communication	RS-422
Expansion	No expansion
Programming Language	Ladder Logic
Input Voltage	100-240V AC
Built-in High-Speed Counter	Up to 60 kHz (single-phase)
Weight	Approx. 0.3 kg
Dimensions	90 x 60 x 75 mm
