FX Series Programmable Controlers Applied Instructions 5
5-206
Setting the third parameter of EXTR K12/K13 during programmed operation in the A500
Parameter
No.
Name
Operation frequency
read/write
Time read/write
Rotation direction
read/write
201
Program set 1
201 1201 2201
202
Program set 1
202 1202 2202
203
Program set 1
203 1203 2203
204
Program set 1
204 1204 2204
205
Program set 1
205 1205 2205
206
Program set 1
206 1206 2206
207
Program set 1
207 1207 2207
208
Program set 1
208 1208 2208
209
Program set 1
209 1209 2209
210
Program set 1
210 1210 2210
211
Program set 2
211 1211 2211
212
Program set 2
212 1212 2212
213
Program set 2
213 1213 2213
214
Program set 2
214 1214 2214
215
Program set 2
215 1215 2215
216
Program set 2
216 1216 2216
217
Program set 2
217 1217 2217
218
Program set 2
218 1218 2218
219
Program set 2
219 1219 2219
220
Program set 2
220 1220 2220
221
Program set 3
221 1221 2221
222
Program set 3
222 1222 2222
223
Program set 3
223 1223 2223
224
Program set 3
224 1224 2224
225
Program set 3
225 1225 2225
226
Program set 3
226 1226 2226
227
Program set 3
227 1227 2227
228
Program set 3
228 1228 2228
229
Program set 3
229 1229 2229
230
Program set 3
230 1230 2230
EXTR K12 K(station No.) K230 D(register No.)
EXTR K12 K(station No.) K230 K(frequency)
EXTR K12 K(station No.) K1230 D(register No.)
EXTR K12 K(station No.) K1230 H(time)
EXTR K12 K(station No.) K2230 D(register No.)
EXTR K12 K(station No.) K2230 K(direction)
Frequency read
Frequency write
Time read
Time write
Rotation direction read
Rotation direction write
Parameter No. +1000
Parameter No. +2000
Parameter No.
