FX Series Programmable Controlers Applied Instructions 5
5-210
5.16.1.1.11 Communication command error codes
The table below shows values set to D8156 after EXTR K10 K13 are executed.
D8155 Contents of error Inverter operation
H0000 Communication is terminated normally (no error)
H0001 The inverter does not give any response
H0002 Timeout error interlocking with M8129. Error occurs when transmission
from the inverter is aborted
H0003 An unspecified station has given a response
H0004 The sum of the data returned by the inverter does not match.
H0005 In parameter read/write, parameters Nos. 400 to 899 are specified but
cannot be supported. Sets error code 6702 into D8067.
H006 The communication port is being used for another function and
therefore cannot be used for the EXTR instruction. Sets error code
6702 into D8067.
H0100 The inverter has transmitted the error code H0 - Computer NAK error.
Communication request data includes an error beyond the permissible
number of retries
If an error occurs
beyond the
permissible number
of retries, the
inverter will come to
an alarm stop
H0101 The inverter has transmitted the error code H1 - Parity error. The
contents are different from the specified parity
H0102 The inverter has transmitted the error code H2 - Sum check error. The
sum check code value in the computer is different to that of the inverter
H0103 The inverter has transmitted the error code H3 - Protocol error. There is
a grammar error in the data received by the inverter, data receive is not
completed within the specified time, or the CR or LF is different from
the parameter setting
H0104 The inverter has transmitted the error code H4 - Framing error. The
stop bit length is different from the default set value
H0105 The inverter has transmitted the error code H5 - Overrun error. Data
sent before previous receive transmission was complete.
H0106 The inverter has transmitted the error code H6. Currently undefined
H0107 The inverter has transmitted the error code H7 - Character error. An
unused character (any character other than 0 to 9, A to F and control
codes) is received
The inverter does
not accept the data
nor does it come to
an alarm stop.
H0108 The inverter has transmitted the error code H8
. Currently undefined
H0109 The inverter has transmitted the error code H9. Currently undefined
H010A The inverter has transmitted the error code HA. This is a mode error. A
parameter write was tried while the inverter was in operation or
computer link mode was not selected.
The inverter does
not accept the data
nor does it come to
an alarm stop.
H010B The inverter has transmitted the error code HB -Instruction code error.
A non-existing instruction code is specified
H010C The inverter has transmitted the error code HC -Data range error. In a
parameter write, data outside the permissible setting range is specified.
The inverter does not accept the data and an alarm does not occur
H010D The inverter has transmitted the error code HD. Currently undefined
H010E The inverter has transmitted the error code HE. Currently undefined
H010F The inverter has transmitted the error code HF. Currently undefined
