Mitsubishi FX1S Series User Manual

FX Series Programmable Controller Diagnostic Devices 6
6-18
For symbol key see page 6-1
M8140 (7)(-)
(Not FX2N,FX2NC)
When ON, clears pulse
output in FNC156(ZRN)
instruction
D8140
D8141
(
7)(-)
Contains the total number of
pulses that have been output
to Y0 using the PLSY or PLSR
instructions. This data is only
available in 32 bit or double
word format.
M8141 to
M8144
Reserved
D8142
D8143
(
7)(-)
Contains the total number of
pulses that have been output
to Y1 using the PLSY or PLSR
instructions. This data is only
available in 32 bit or double
word format.
M8145 (-)
(Not FX2N,FX2NC)
Y000 Pulse output stop
command
D8145 (-)
(Not FX2N,FX2NC)
FNC156(ZRN),
FNC158(DRVI),
FNC159(DRVA) Bias value
setting (default:0)
M8146 (-)
(Not FX2N,FX2NC)
Y001 Pulse output stop
command
D8146 (-)
(Not FX2N,FX2NC)
FNC156(ZRN),
FNC158(DRVI),
FNC159(DRVA)
Max. speed setting
(default:100,000)
M8147 (
7)
(Not FX2N,FX2NC)
Y000 Pulse output monitor
(Busy/Ready)
D8147 (-)
(Not FX2N,FX2NC)
M8148 (7)
(Not FX2N,FX2NC)
Y001 Pulse output monitor
(Busy/Ready)
D8148 (-)
(Not FX2N,FX2NC)
FNC156(ZRN),
FNC158(DRVI),
FNC159(DRVA) Acceleration/
Deceleration time setting
(default:100)
Diagnostic
Device
Operation
Diagnostic
Device
Operation
