FX Series Programmable Controller Diagnostic Devices 6
6-24
Error Detection
Device
Stored Error
Number
Associated Meaning Action
D8064
Parameter
error
0000 No error
STOP the PLC, check
parameter, if incorrect
change to a suitable
value
6401 Program sum check error
6402 Memory capacity setting error
6403 Latched device area setting error
6404 Comment area setting error
6405 File register area setting error
6406 - 6408 Reserved
6409 Other setting error
Error Detection
Device
Stored Error
Number
Associated Meaning Action
D8065
Syntax error
0000 No error
During programming,
each instruction is
checked as it is entered.
If a syntax error is
detected, re-enter the
instruction correctly
6501
Incorrect instruction/ device symbol/
device number combination
6502
No timer or counter coil before setting
value
6503
1)No setting value following either a timer
or a counter coil
2)Insufficient number of operands for an
applied instruction
6504
1)The same label number is used more
than once
2)The same interrupt input or high speed
counter input is used more than once
6505
Device number is outside the allowable
range
6506 Invalid applied instruction
6507
Invalid Pointer device [P] assignment for
Jump or Call instruction
6508
Invalid Interrupt pointer device [I]
assignment
6509 Other error
6510 MC nesting (N) number error
6511
The same interrupt input or high speed
counter input is used more than once
