Mitsubishi FX1S Series User Manual

HEAD OFFICE: MITSUBISHI DENKI BLDG MARUNOUCHI TOKYO 100-8310 TELEX: J24532 CABLE MELCO TOKYO
HIMEJI WORKS: 840, CHIYODA CHO, HIMEJI, JAPAN
JY992D88101C
(MEE 0109)
Effective Sep. 2001
Specification are subject
to change without notice.
PROGRAMMING MANUAL II
THEFXSERIESOFPROGRAMMABLECONTROLLER
(FX
1S ,FX 1N ,FX 2N, FX 2NC )

Mitsubishi FX1S Series Specifications

General

Model	FX1S Series
I/O Points	10 to 30 points
Program Memory	2000 steps
Power Supply	AC
Communication	RS-422
Expansion	No expansion
Programming Language	Ladder Logic
Input Voltage	100-240V AC
Built-in High-Speed Counter	Up to 60 kHz (single-phase)
Weight	Approx. 0.3 kg
Dimensions	90 x 60 x 75 mm
