FX Series Programmable Controllers Devices in Detail 4
4-25
If any high speed comparison instructions (FNC’s 53, 54, 55) are used, X0 and X1 must resort
to software counting. In this case, please see the table below:
Unit
Function
Number
Max. Combined
Signal Frequency
FX
2N &FX2NC
53 or 54 11 kHz
55 5.5 kHz
FX
1S &FX1N 53 or 54 30 kHz
Calculating the maximum combined counting speed on FX1S:
Thisiscalculatedasfollows:(2 phase counter speed x number of counted edges) :
(the sum of the speeds of the active 1 phase counters).

Mitsubishi FX1S Series Specifications

General

Model	FX1S Series
I/O Points	10 to 30 points
Program Memory	2000 steps
Power Supply	AC
Communication	RS-422
Expansion	No expansion
Programming Language	Ladder Logic
Input Voltage	100-240V AC
Built-in High-Speed Counter	Up to 60 kHz (single-phase)
Weight	Approx. 0.3 kg
Dimensions	90 x 60 x 75 mm
