Mitsubishi FX2N-10GM - Applicable Devices

FX Series Positioning Controllers Program format 5
5-41
5.7.2 Applicable devices
*1 When PARA. 56 (general purpose declaration) is set to "1" to "4", the [ZRN], [FWD] and
[RVS] terminals can be used for general purpose inputs (Refer to Section 4.4.5).
*2 Lower numbers are assigned to extension blocks from the one closest to the FX
2N
-20GM
main unit. The total number of extension I/Os must be 48 or less (Refer to Section 1.4.5.).
Example of I/O assignment
*3 Battery backup area
When the power is turned off, the FX
2N
-20GM stores the status just before the power is turned
off with the lithium battery FX
2NC
-32BL. The FX
2N
-10GM stores the status with an EEPROM.
The number of used file registers should be set in PARA. 101.
*4 The use of extension blocks is not possible with the FX
2N
-10GM. When more I/Os are
required, use a programmable controller.
*5 When manual pulse generators or interrupt positioning instructions (cod 31, cod 71 and cod
72) are used, a part or the whole of these cannot be used for general purpose inputs (Refer
to Section 5.6.11).
Table 5.16: Applicable device
s
FX
2N
-10GM FX
2N
-20GM
Main unit Main unit Extension
Input relays
(X) *5
X00 to X03 4 points
X375 to X377 3 points *1
X00 to X07 8 points
X372 to X377 6 points *1
X10 to X67
48 points *2
Output relays
(Y)
Y00 to Y05 6 points Y00 to Y07 8 points
Y10 to Y67
48 points*2
Auxiliary relays
(M)
M0 to M511 512 points
(general purpose)
M9000 to M9175 (special)
M0 to M99 (general purpose)
100 points
M100 to M511 (general purpose)
412 points *3
M9000 to M9175 (special)

Data registers
(D)
D0 to D1999 2000 points
(general purpose)
D4000 to D6999 (files)
3000 points*3
D9000 to D9313 (special)
D0 to D99 (general purpose)
100 points
D100 to D3999 (general purpose)
3900 points*3
D4000 to D6999 (files)
3000 points *3
D9000 to D9599 (special)

Index
registers
V0 to V7 (16-bit)8 points
Z0 to Z7 (32-bit)8 points
V0 to V7 (16-bit) 8 points
Z0 to Z7 (32-bit) 8 points

Pointers P0 to P127 128 points P0 to P255 256 points

FX
2N
-
20GM
X00 to X07
FX
2NC
-
16EX
X10
to
X27
Y00 to Y07
FX
2NC
-
16EYT
FX
2N
-
16EX
FX
2NC
-CNVIF
X30
to
X47
Y10
to
Y27
