Mitsubishi FX2N-10GM - Continuous Pass Operation (FX 2 N -20 GM)

FX Series Positioning Controllers Program Examples 9
9-21
9.4.5 Continuous pass operation (FX
2N
-20GM)
1) Outline of positioning
The machine repeats locus operation at a constant speed without stop.
2) Operating procedure
c
The machine returns to the zero point by the start command only at the first time.
d
The machine moves to the target address in a linear route.
e
The output Y0 turns on, and the machine repeats locus operation 10 times.
f
The output Y0 turns off, and the machine returns to the zero point.
3) Operation chart
0A
(-300,400)
E
F
(-400,300)
×
HI
D
C
JG
(300,400)
(400,300)
(400,-300)
(300,-400)(-300,-400)
(-400,-300)
(400,0)
B
Zero
point
y axis
x axis
×
×
×
