4. Parameters
4.1 Notes on Parameters in General
Set parameters to determine the operating condition of the positioning unit.
The positioning unit can satisfy diversified needs through parameter setting in accordance with
the operation specifications and the control specifications.
Parameters are mainly classified into the following three types.
• Positioning parameters (PARA. 0 ~)
Determine the units, the speed, etc. for positioning control.
• I/O control parameters (PARA. 30 ~)
Determine the contents related to the I/Os of the positioning unit such as the method of
specifying the program No., the destination of the m code, etc.
• System parameters (PARA. 100 ~)
Determine the memory size of the program, the number of file registers, etc.
In the FX
2N
-20GM, the positioning parameters and the I/O control parameters for independent
2-axis operation must be set for each of the X and Y axes. The parameters for simultaneous 2-
axis operation need only be set for the X axis. The settings for the Y axis are not required. In
the FX
2N
-10GM, the parameters must be set for one axis (the X axis) exclusively.
Peripheral units
E-TP teaching panel
FX-PCK-KIT-98/GM personal
computer software
FX-30DU-GM data access unit
Parameter memory
Special data registers
Positioning programs
Write
Read / UseOverwrite
Power turned ON. MANU
to AUTO.
