8.1.7 Each signal fetch timing
In order to write programs correctly, the writer must be aware of the timing in which the posi-
tioning unit detects and executes operations in response to the various inputs.
Special auxiliary relays for the instruction input is always observed in the AUTO mode.
(Refer to Section 6.2)
Table 8.3: Each signal fetch timing
Input signals
MANU mode AUTO mode
Motor stopped Motor running Motor stopped Motor running
SVRDY Before drive.
Continuously
monitored
Before drive.
Continuously
monitored
SVEND After drive

After drive

PGO

After near-point
DOG actuation.

After near-point
DOG actuation.
DOG
Before zero
return drive.
During zero
return operation.
Before zero
return drive.
During zero
return operation.
START

During READY
status.

STOP Continuously monitored.
MANU Continuously monitored.
ZRN
Continuously
monitored

During standby
after END step.

FWD, RVS
(JOG+, JOG-)
Continuously monitored During standby after END step.
LSF, LSR Before drive.
Continuously
monitored
Before drive.
Continuously
monitored
X00 to X07
When the manual pulse generator is
operating.
When the man-
ual pulse genera-
tor is operating,
During standby
after END step.
During execution
of INT, SINT,
DINT instruc-
tions.
General purpose inputs
X00 or more

When the corresponding instruction
is executed.
Inputs specified by
parameters.

Continuously monitored.
