169
FX3UC Series Programmable Controllers
User’s Manual - Hardware Edition
6 Output Specification and External Wiring
6.2 Transistor Output
1
Outline
2
External
Dimensions
3
Generic
Specifications
4
Power Supply
Specifications
5
Input
Specifications
6
Output
Specifications
7
Examples of
Wiring for
Various Uses
8
Terminal Block
9
CC-Link/LT
Master FX
3UC
(LT only)
10
Display module
FX
3UC
(LT only)
6.2 Transistor Output
6.2.1 Transistor Output Specifications (Sink output type)
The table below shows the output specifications of the FX3UC-MT/D, FX3UC-32MT-LT Main unit, FX0N/
FX
2N/FX2NC output extension blocks (sink output type).
Outputs in the main unit are restricted by the simultaneous ON ratio.
→ For the restriction in simultaneous ON ratio, refer to Subsection 6.2.3.
*1. When the two COM terminals are connected outside the PLC, resistance load is 1.6A or less.
Item Transistor output (sink) specifications
Number of output
points
FX3UC-16MT/D 8 points
FX3UC-32MT/D 16 points
FX3UC-64MT/D 32 points
FX3UC-96MT/D 48 points
FX3UC-32MT-LT 16 points
FX0N-8EYT(-H), FX2N-8EYT(-H) 8 points
FX2N-16EYT(-C), FX2NC-16EYT 16 points
FX2NC-32EYT 32 points
Connecting type
FX3UC-MT/D, FX3UC-32MT-LT,
FX
2NC-16EYT, FX2NC-32EYT
FX
2N-16EYT-C
Connector
FX0N-8EYT(-H), FX2N-8EYT(-H),
FX
2N-16EYT
Terminal block
Output type/form Transistor/Sink output
External power supply 5 to 30V DC
Max. load
Resistance
load
FX3UC-MT/D
FX
3UC-32MT-LT
Y000 to Y003 0.3A/1 points Make sure that the total load
current of 8 resistance load points
is 0.8A
*1
or less.
Y004 or later 0.1A/1 points
FX2NC-16EYT, FX2NC-32EYT 0.1A/1 points
Make sure that the total load
current of 8 resistance load points
is 0.8A or less.
FX2N-16EYT-C 0.3A/1 points
Make sure that the total load
current of 16 resistance load points
is 1.6A or less.
FX2N-8EYT
FX
0N-8EYT
FX
2N-16EYT
FX
0N-16EYT
0.5A/1 points
The total load current of resistance
loads per common terminal should
be the following value.
4points/common: 0.8A
8points/common: 1.6A
FX2N-8EYT-H
FX
0N-8EYT-H
1A/1 points
Make sure that the total load
current of 4 resistance load points
is 2A or less.
Inductive
load
FX3UC-MT/D
FX
3UC-32MT-LT
Y000 to Y003
7.2W/1 points
(24V DC)
Make sure that the total load of 16
inductive load points is 38.4W/24V
DC or less.
Y004 or later
2.4W/1 points
(24V DC)
FX2NC-16EYT, FX2NC-32EYT 2.4W/1 points (24V DC)
FX2N-16EYT-C 7.2W/1 points (24V DC)
FX2N-8EYT, FX0N-8EYT,
FX
2N-16EYT, FX0N-16EYT
12W/1 points (24V DC)
FX2N-8EYT-H, FX0N-8EYT-H 24W/1 points (24V DC)
Open circuit leakage current 0.1mA or less/30V DC
To Next Page
