171
FX3UC Series Programmable Controllers
User’s Manual - Hardware Edition
6 Output Specification and External Wiring
6.2 Transistor Output
1
Outline
2
External
Dimensions
3
Generic
Specifications
4
Power Supply
Specifications
5
Input
Specifications
6
Output
Specifications
7
Examples of
Wiring for
Various Uses
8
Terminal Block
9
CC-Link/LT
Master FX
3UC
(LT only)
10
Display module
FX
3UC
(LT only)
6.2.2 Transistor Output Specifications (Source output type)
The table below shows the output specifications of the FX3UC-MT/DSS Main unit, FX2NC/FX2N output
extension blocks (source output type).
Outputs in the main unit are restricted by the simultaneous ON ratio.
→ For the restriction in simultaneous ON ratio, refer to Subsection 6.2.3.
*1. When the two +V terminals are connected outside the PLC, resistance load is 1.6A or less.
Item Transistor output (source) specifications
Number of
output
points
FX3UC-16MT/DSS 8 points
FX3UC-32MT/DSS 16 points
FX3UC-64MT/DSS 32 points
FX3UC-96MT/DSS 48 points
FX2N-8EYT-ESS/UL 8 points
FX2N-16EYT-ESS/UL,
FX
2NC-16EYT-DSS
16 points
FX2NC-32EYT-DSS 32 points
Connecting type
FX3UC-MT/DSS,
FX
2NC output extension block,
Connector
FX2N/FX0N output extension block Terminal block
Output type/form Transistor/Source output
External power supply 5 to 30V DC
Max.
load
Resistance
load
FX3UC-
MT/DSS
Y000 to Y003 0.3A/1 points Make sure that the total load
current of 8 resistance load points
is 0.8A
*1
or less.
Y004 or later 0.1A/1 points
FX2NC-16EYT-DS, FX2NC-32EYT-DS 0.1A/1 points
Make sure that the total load
current of 8 resistance load points
is 0.8A or less.
FX2N-8EYT-ESS/UL,
FX
2N-16EYT-ESS/UL
0.5A/1 points
The total load current of resistance
loads per common terminal should
be the following value.
4points/common: 0.8A
8points/common: 1.6A
Inductive
load
FX3UC-
MT/DSS
Y000 to Y003
7.2W/1 points
(24V DC)
Make sure that the total load of 16
inductive load points is 38.4W/24V
DC or less.
Y004 or later
2.4W/1 points
(24V DC)
FX2NC-16EYT-DSS,
FX
2NC-32EYT-DSS
2.4W/1 points (24V DC)
FX2N-8EYT-ESS/UL,
FX
2N-16EYT-ESS/UL
12W/1 points (24V DC)
Open circuit leakage current 0.1mA or less/30V DC
ON voltage 1.5V or less
Response
time
OFF → ON
FX3UC-
MT/DSS
Y000 to Y002 5µs or less/10mA or more (5 to 24V DC)
Y003 or later 0.2ms or less/100mA (24V DC)
Extension
blocks
For FX2NC Series 0.2ms or less/100mA
For FX2N Series 0.2ms or less/200mA
ON → OFF
FX3UC-
MT/DSS
Y000 to Y002 5µs or less/10mA or more (5 to 24V DC)
Y003 or later 0.2ms or less/100mA (24V DC)
Extension
blocks
For FX2NC Series 0.2ms or less/100mA
For FX2N Series 0.2ms or less/200mA
Circuit insulation Photocoupler insulation
Output operation
display
FX3UC-MT/DSS,
Extension blocks
LED on panel lights when photocoupler is driven.
To Next Page
