Mitsubishi FX3UC Series User Manual

182
FX3UC Series Programmable Controllers
User’s Manual - Hardware Edition
6 Output Specification and External Wiring
6.3 Relay Output [FX2NC/FX0N/FX2N Extension Blocks]
6.3.5 Example of external wiring
WIRING PRECAUTIONS
• Before cleaning or retightening terminals cut off all phases of the power supply externally.
Failure to do so may cause electric shock.
5 to
30V DC
2A
Fuse
Load
Y000
COM1
Y001
COM1
FX 3UC -32MT/D
(Vacant terminal)
5A
LED
Relay
Solenoid
Fuse
COM1
Y000
Y001
Y002
Y003
FX 2N relay output
extension block
(4point common)
COM2
Y004
Y005
Y006
Y007
Fuse
5A
Contactor
Solenoid
AC power supply
250V AC or less
FX 2N relay output
extension block
(8point common)
COM1
Y000
Y001
Y002
Y003
Fuse
5A
Relay
Contactor
Solenoid
Solenoid
Y004
Y005
Y006
Y007
Fuse
5A
FX 2NC relay output
extension block
COM1
Y000
Y001
Y002
Y003
Fuse
5A
Relay
Contactor
Solenoid
Solenoid
Y004
Y005
Y006
Y007
Fuse
5A
FX 2NC -CNV-IF
(Vacant terminal)
(Vacant terminal)
(Vacant terminal)
(Vacant terminal)
