8 Terminal Block Specifications and External Wiring
8.6 FX-16E-TB/UL, FX-32E-TB/UL
8.6.3 Example of output external wiring [Source wiring]
1. When connected to the FX3UC-MT/DSS and FX2NC-EYT-DSS output connector
WIRING PRECAUTIONS
• Before cleaning or retightening terminals cut off all phases of the power supply externally.
Failure to do so may cause electric shock.
PLC's
output No.
 0 to  7 (Higher Nos.)0 to 7 (Lower Nos.)
1 3
4
5
60 2
7 1 3
0 2 4
5
6
7
7
6
5
4
3
2
1
0 0
1
2
3
4
5
6
7
+V0
24V
DC
MC1 MC2
COM
COM
COM
COM
COM
COM
COM
COM
Fuse Fuse Fuse
*1
*1."+V1" or "+V2" in accordance with connected connector
Vacant
terminal
