FX3UC Series Programmable Controllers
User’s Manual - Hardware Edition
2 External Dimensions and Terminal Arrangement
2.1 External Dimensions (MASS/Installation/Accessories)
FX2N-10PG
• Installation: DIN rail of 35 mm (1.38") in
width or screws
• Accessories: Label for indication of
special unit/block number,
Manual supplied with
product
• Terminal block: Connector
• The extension cable is already connected to
the extension block
FX
2N-10GM/FX2N-20GM
• Installation: DIN rail of 35mm (1.38") in
width
• Accessories: FX
2NC-100MPCB power
cable, FX
2N-GM-5EC
extension cable, label for
indication of special unit/
block number,
FX
2NC-100BPCB power
cable (Only FX
2N-20GM),
Manual supplied with
product
• Terminal block: Connector
Model name W(mm)
MASS
(Weight)
FX
2N-10PG
43
(1.70")
0.2
(0.44lbs)
Type Model name W(mm)
MASS
(Weight)
AFX
2N-10GM
60
(2.37")
0.3
(0.66lbs)
BFX
2N-20GM
86
(3.39")
0.4
(0.88lbs)
74(2.92")
87(3.43")
80(3.15")
(mounting hole pitch)
90(3.55")
Unit:mm (inches)
4(0.16")
9(0.36")
W:43(1.70")
2-φ4.5 mounting holes
74(2.92")
90(3.55")
Unit:mm (inches)
13(0.52")
W:60(2.37")
74(2.92")
90(3.55")
Unit:mm (inches)
13(0.52")
W:86(3.39")
B type
A type
