162
204
*1
CH Logging points after trigger (Un\G1048 to Un\G1051) is set to
a value outside the range of 1 to 10000.
The channel where the error has occurred fits in .
Set a value within the range of 1 to 10000 in CH
Logging points after trigger (Un\G1048 to
Un\G1051).
205
*1
CH Level trigger condition setting (Un\G1056 to Un\G1059) is set
to a value outside the range of 0 to 3.
The channel where the error has occurred fits in .
Set one of the following values in CH Level trigger
condition setting (Un\G1056 to Un\G1059).
• Disable (0)
• Above (1)
• Below (2)
• Pass through (3)
206
*1
CH Trigger data (Un\G1064 to Un\G1067) is set to a value outside
the range of 0 to 4999.
The channel where the error has occurred fits in .
Set a value within the range of 0 to 4999 in CH
Trigger data (Un\G1064 to Un\G1067).
207
*1
CH Logging hold request (Un\G1008 to Un\G1011) is set to a
value other than 0 and 1.
The channel where the error has occurred fits in .
Set OFF (0) or ON (1) in CH Logging hold request
(Un\G1008 to Un\G1011).
208
*1
CH Logging enable/disable setting (Un\G1000 to Un\G1003) is set
to Enable (0), and besides the input signal error detection function
or the input signal error detection extension function is enabled.
The channel where the error has occurred fits in .
To use the logging function, set the following buffer
memory areas as below.
• Set Disable (0) in Input signal error detection
extension setting (Un\G27)
• Set Disable (1) in Input signal error detection
setting (Un\G47).
210
*1
CH Flow amount integration enable/disable setting (Un\G1300 to
Un\G1303) is set to a value other than 0 and 1.
The channel where the error has occurred fits in .
Set Enable (0) or Disable (1) in CH Flow amount
integration enable/disable setting (Un\G1300 to
Un\G1303).
Conversion speed is set to 20µs or 80µs, and besides CH Flow
amount integration enable/disable setting (Un\G1300 to Un\G1303)
is set to Enable (0).
The channel where the error has occurred fits in .
To use the flow amount integration function, set the
conversion speed to 1ms.
211
*1
CH Integration cycle setting (Un\G1308 to Un\G1311) is set to a
value outside the range of 1 to 5000.
The channel where the error has occurred fits in .
Set a value within the range of 1 to 5000 in CH
Integration cycle setting (Un\G1308 to Un\G1311).
212
*1
The set value in CH Integration cycle setting (Un\G1308 to
Un\G1311) is shorter than the update cycle of CH Scaling value
(digital operation value) (Un\G54 to Un\G57).
The channel where the error has occurred fits in .
Set CH Integration cycle setting (Un\G1308 to
Un\G1311) so that the integration cycle is equal to or
longer than the update cycle of CH Scaling value
(digital operation value) (Un\G54 to Un\G57).
For the setting method of the integration cycle, refer
to the following.
Flow amount integration function ( Page 110,
Section 8.15)
213
*1
CH Flow amount time unit setting (Un\G1316 to Un\G1319) is set
to a value outside the range of 0 to 2.
The channel where the error has occurred fits in .
Set one of the following values in CH Flow amount
time unit setting (Un\G1316 to Un\G1319).
•/s (0)
•/min (1)
•/h (2)
214
*1
CH Unit scaling setting (Un\G1324 to Un\G1327) is set to a value
outside the range of 0 to 4.
The channel where the error has occurred fits in .
Set one of the following values in CH Unit scaling
setting (Un\G1324 to Un\G1327).
•× 1 (0)
• × 10 (1)
• × 100 (2)
• × 1000 (3)
• × 10000 (4)
215
*1
CH Flow amount integration temporary stop request (Un\G1356 to
Un\G1359) is set to a value other than 0 and 1.
The channel where the error has occurred fits in .
Set No request (0) or Temporary stop request (1) in
CH Flow amount integration temporary stop
request (Un\G1356 to Un\G1359).
Error code
(decimal)
Description and cause of error Action
To Next Page
