Mitsubishi L Series User Manual

179
APPENDICES
A
Appendix 2 Details of Buffer Memory Addresses
(12)Digital clipping enable/disable setting (Un\G29)
Set whether the digital clipping function is enabled or disabled, for each channel.
For details on the digital clipping function, refer to the following.
• Digital Clipping Function ( Page 90, Section 8.12)
(a) Enabling the setting
Turn OFF → ON → OFF Operating condition setting request (Y9) to enable the setting.
(b) Default value
All channels are set to Disable (1).
(13)CH Maximum value (Un\G30, Un\G32, Un\G34, Un\G36), CH Minimum value
(Un\G31, Un\G33, Un\G35, Un\G37)
The maximum and minimum values of converted digital output value are stored as signed 16-bit binary.
In the following cases, CH Maximum value (Un\G30, Un\G32, Un\G34, Un\G36) and CH Minimum value
(Un\G31, Un\G33, Un\G35, Un\G37) are updated with the current value.
• When turning OFF → ON → OFF Operating condition setting request (Y9) changes the setting
• When Maximum value/minimum value reset request (YD) is turned OFF → ON → OFF
● For the channel to which the averaging processing is specified, the maximum and minimum values are stored at
averaging processing time intervals.
● In CH
Maximum value (Un\G30, Un\G32, Un\G34, Un\G36) and CH Minimum value (Un\G31, Un\G33, Un\G35,
Un\G37), the values calculated by each function is stored using the following functions:
• Digital clipping function
• Scaling function
• Shift function
• Difference conversion function
(14)Input signal error detection setting (Un\G47)
Set whether the alarm output of input signal error detection is enabled or disabled for each channel. Only the
lower upper limit detection can be used as the detection method of an input signal error in this area.
• Input Signal Error Detection Function ( Page 69, Section 8.7)
(a) Enabling the setting
Turn OFF → ON → OFF Operating condition setting request (Y9) to enable the setting.
00000000000 CH1CH2CH3CH40
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b0b1b2b3b4
0: Enabled
1: Disabled
Data for b4 to b15 are fixed to "0".
00000000000 CH1CH2CH3CH4 0
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b0b1b2b3b4
0: Enabled
1: Disabled
Data for b4 to b15 are fixed to "0".
