198
(46)CH Flow amount integration enable/disable setting (Un\G1300 to Un\G1303)
Set whether the flow amount integration function is enabled or disabled.
For details on the flow amount integration function, refer to the following.
• Flow amount integration function ( Page 110, Section 8.15)
(a) Enabling the setting
Turn OFF → ON → OFF Operating condition setting request (Y9) to enable the setting.
(b) Default value
All channels are set to Disable (1).
● In the channel where a setting value other than the above is set, an error occurs. The error code is stored in Latest error
code (Un\G19) and Error flag (XF) is turned to ON.
● In the channel where the conversion speed is set to 20µs or 80µs and CH Flow amount integration enable/disable
setting (Un\G1300 to Un\G1303) is Enabled (0), an error occures. The error code is stored in Latest error code (Un\G19),
Error flag (XF) is turned to ON, and the flow amount integration function is not enabled.
(47)CH Integration cycle setting (Un\G1308 to Un\G1311)
Set the integration cycle of flow amount integration in each channel.
For details on the flow amount integration function, refer to the following.
• Flow amount integration function ( Page 110, Section 8.15)
(a) Setting range
Setting range is 1 to 5000 (ms).
(b) Default value
All channels are set to 4 (ms).
In the channel where the following conditions are set, an error occurs. Then, the error code is stored in Latest error code
(Un\G19), Error flag (XF) is turned to ON and the flow amount integration function cannot be performed.
• When a value other than the above is set
• When the calculated integration cycle is below the data updated cycle of CH Scaling value (digital operation
value) (Un\G54 to Un\G57)
Flow amount integration enable/disable setting Setting value
Enable 0
Disable 1
