Appendix 2 Details of Buffer Memory Addresses
(48)CH Flow amount time unit setting (Un\G1316 to Un\G1319)
Set a conversion value to convert the time unit of instantaneous flow amount to ms.
Set CH Flow amount time unit setting (Un\G1316 to Un\G1319) to the range of the flow meter connected to the
A/D converter module.
For details on the flow amount integration function, refer to the following.
• Flow amount integration function ( Page 110, Section 8.15)
When the range of the flow meter is "cm
3
/s", set / (0).
(a) Default value
All channels are set to /s (0).
In the channel where a setting value other than the above is set, an error occurs. The error code is stored in Latest error
code (Un\G19), Error flag (XF) is turned to ON, and the flow amount integration function is not enabled.
(49)CH Unit scaling setting (Un\G1324 to Un\G1327)
Set the unit scaling that is used for the flow amount integration function.
For details on the flow amount integration function, refer to the following.
• Flow amount integration function ( Page 110, Section 8.15)
(a) Default value
All channels are set to × 1 (0).
In the channel where a setting value other than the above is set, an error occurs. The error code is stored in Latest error
code (Un\G19), Error flag (XF) is turned to ON, and the flow amount integration function is not enabled.
Flow amount time unit Setting value
/s 0
/min 1
/h 2
Unit scaling Setting value
× 1 0
× 10 1
× 100 2
× 1000 3
× 10000 4
Ex.
