200
(50)CH Integrated flow amount (Un\G1332 to Un\G1339)
This is the area for storing the result of the integral processing performed by the flow amount integration function.
The integrated flow amount is stored with 32-bit signed binary.
(a) Storage range
The value is stored within the range of 0 to 2147483647.
(51)CH Integration cycle monitor value (Un\G1348 to Un\G1351)
This is the area for storing the integration cycle which is calculated from the update cycle of CH Scaling value
(digital operation value) (Un\G54 to Un\G57).
For details on the flow amount integration function, refer to the following.
• Flow amount integration function ( Page 110, Section 8.15)
(a) Storage range
When CH Flow amount integration enable/disable setting (Un\G1300 to Un\G1303) is Enable (0), the value is
stored within the range of 1 to 5000. When it is Disable (1), the value is fixed to 0.
(52)CH Flow amount integration temporary stop request (Un\G1356 to Un\G1359)
Stops the integral processing temporarily while the flow amount integration function is operating.
For details on the flow amount integration function, refer to the following.
• Flow amount integration function ( Page 110, Section 8.15)
• When CH Flow amount integration temporary stop request (Un\G1356 to Un\G1359) is turned No
request (0) → Temporary stop request (1) while the flow amount integration function is operating, the flow
amount integration function temporarily stops.
• When CH Flow amount integration temporary stop request (Un\G1356 to Un\G1359) is turned
Temporary stop request (1) → No request (0) while the flow amount integration function temporarily stops,
the flow amount integration function restarts.
(a) Default value
All channels are set to No request (0).
In the channel where a setting value other than the above is set, an error occurs. The error code is stored in Latest error
code (Un\G19), Error flag (XF) is turned to ON, and the setting is ignored.
Flow amount integration temporary stop request Setting value
No request 0
Temporary stop request 1
Sign bit
0: Positive (fixed to 0)
Data section Data section
b15 b0b15 b0
CH1 Integrated flow amount (L) (Un/G1332)CH1 Integrated flow amount (H) (Un/G1333)
