Mitsubishi L Series - Page 31

29
CHAPTER 3 SPECIFICATIONS
3
3.5 List of Buffer Memory Addresses
184
B8
H
System area ⎯⎯to to
189
BD
H
190
BE
H
CH1 Difference conversion status flag 0 R
191
BF
H
CH2 Difference conversion status flag 0 R
192
C0
H
CH3 Difference conversion status flag 0 R
193
C1
H
CH4 Difference conversion status flag 0 R
194
C2
H
System area ⎯⎯to to
199
C7
H
200
C8
H
Pass data classification setting 0 R/W
201
C9
H
System area ⎯⎯
202
CA
H
CH1 Industrial shipment settings offset value (L) 0 R/W
203
CB
H
CH1 Industrial shipment settings offset value (H) 0 R/W
204
CC
H
CH1 Industrial shipment settings gain value (L) 0 R/W
205
CD
H
CH1 Industrial shipment settings gain value (H) 0 R/W
206
CE
H
CH2 Industrial shipment settings offset value (L) 0 R/W
207
CF
H
CH2 Industrial shipment settings offset value (H) 0 R/W
208
D0
H
CH2 Industrial shipment settings gain value (L) 0 R/W
209
D1
H
CH2 Industrial shipment settings gain value (H) 0 R/W
210
D2
H
CH3 Industrial shipment settings offset value (L) 0 R/W
211
D3
H
CH3 Industrial shipment settings offset value (H) 0 R/W
212
D4
H
CH3 Industrial shipment settings gain value (L) 0 R/W
213
D5
H
CH3 Industrial shipment settings gain value (H) 0 R/W
214
D6
H
CH4 Industrial shipment settings offset value (L) 0 R/W
215
D7
H
CH4 Industrial shipment settings offset value (H) 0 R/W
216
D8
H
CH4 Industrial shipment settings gain value (L) 0 R/W
217
D9
H
CH4 Industrial shipment settings gain value (H) 0 R/W
218
DA
H
CH1 User range settings offset value (L) 0 R/W
219
DB
H
CH1 User range settings offset value (H) 0 R/W
220
DC
H
CH1 User range settings gain value (L) 0 R/W
221
DD
H
CH1 User range settings gain value (H) 0 R/W
222
DE
H
CH2 User range settings offset value (L) 0 R/W
223
DF
H
CH2 User range settings offset value (H) 0 R/W
224
E0
H
CH2 User range settings gain value (L) 0 R/W
225
E1
H
CH2 User range settings gain value (H) 0 R/W
226
E2
H
CH3 User range settings offset value (L) 0 R/W
227
E3
H
CH3 User range settings offset value (H) 0 R/W
228
E4
H
CH3 User range settings gain value (L) 0 R/W
229
E5
H
CH3 User range settings gain value (H) 0 R/W
230
E6
H
CH4 User range settings offset value (L) 0 R/W
231
E7
H
CH4 User range settings offset value (H) 0 R/W
Address
(decimal)
Address
(hexadecimal)
Name
Default
*1
Read/Write
*2
