CHAPTER 3 SPECIFICATIONS
3
3.5 List of Buffer Memory Addresses
1042
412
H
CH3 Logging cycle unit setting 1 R/W
1043
413
H
CH4 Logging cycle unit setting 1 R/W
1044
414
H
System area ⎯⎯to to
1047
417
H
1048
418
H
CH1 Logging points after trigger 5000 R/W
1049
419
H
CH2 Logging points after trigger 5000 R/W
1050
41A
H
CH3 Logging points after trigger 5000 R/W
1051
41B
H
CH4 Logging points after trigger 5000 R/W
1052
41C
H
System area ⎯⎯to to
1055
41F
H
1056
420
H
CH1 Level trigger condition setting 0 R/W
1057
421
H
CH2 Level trigger condition setting 0 R/W
1058
422
H
CH3 Level trigger condition setting 0 R/W
1059
423
H
CH4 Level trigger condition setting 0 R/W
1060
424
H
System area ⎯⎯to to
1063
427
H
1064
428
H
CH1 Trigger data 54 R/W
1065
429
H
CH2 Trigger data 55 R/W
1066
42A
H
CH3 Trigger data 56 R/W
1067
42B
H
CH4 Trigger data 57 R/W
1068
42C
H
System area ⎯⎯to to
1071
42F
H
1072
430
H
Level data 0 0 R/W
1073
431
H
Level data 1 0 R/W
1074
432
H
Level data 2 0 R/W
1075
433
H
Level data 3 0 R/W
1076
434
H
Level data 4 0 R/W
1077
435
H
Level data 5 0 R/W
1078
436
H
Level data 6 0 R/W
1079
437
H
Level data 7 0 R/W
1080
438
H
Level data 8 0 R/W
1081
439
H
Level data 9 0 R/W
1082
43A
H
CH1 Trigger setting value 0 R/W
1083
43B
H
CH2 Trigger setting value 0 R/W
1084
43C
H
CH3 Trigger setting value 0 R/W
1085
43D
H
CH4 Trigger setting value 0 R/W
Address
(decimal)
Address
(hexadecimal)
Name
Default
*1
Read/Write
*2
