97
CHAPTER 8 FUNCTIONS
8
8.13 Difference Conversion Function
(d) Operation of when the averaging processing is set
If the difference conversion starts while the averaging processing is set, the scaling value (digital operation
value) at the completion of the averaging processing is determined as the difference conversion reference
value. In addition, CH Difference conversion status flag (Un\G190 to Un\G193) changes to Converting
difference (1).
● The difference conversion function can be started at any timing.
● When the difference conversion function is used with the digital clipping function, scaling function, and shift function, each
scaling value (digital operation value) is determined as a difference conversion reference value.
● If other than No request (0) or Trigger request (1) is set in CH Difference conversion trigger (Un\G172 to Un\G175)
during the difference conversion, an error occurs. Though the difference conversion continues.
● Even if the digital clipping function, scaling function, and shift function are set valid, the difference conversion reference
value is not updated. To update the difference conversion reference value, stop the difference conversion and restart it.
To Next Page
